Blue Smart IP65 Lader 24 13 DC connector
€204,25
Angebotspreis
€204,25
Normaler Preis
€215,00
Zu Produktinformationen springen
Auf Lager
Terug naar de winkel
Blue Smart IP65 Lader 24 13 DC connector
€204,25
Angebotspreis
€204,25
Normaler Preis
€215,00
BPC241331124
De Blue Smart IP65-lader is de nieuwe professionele acculader met ingebouwde Bluetooth. De Blue Smart IP65-lader kan worden gebruikt voor apparaten in uw werkplaats en voor motorvoertuigen, zoals (klassieke) auto's, motoren, boten en campers.
Nieuw: IP65 12/5 is vervangen door kleiner equivalent model: IP65s 12/5
Specificaties
| Kenmerk | Waarde |
|---|---|
| acConnectionTerminalType | Cable of 1.8 meter (6 feet) with US NEMA 5-15 plug |
| acInputFrequencyRange | [45, 65] Hz |
| aCInputVoltageRange | [100, 130] VAC |
| backCurrentDrain | 1 mA |
| backCurrentDrainMonth | 0.7 Ah/mo |
| batteryConnectionTerminalType | Red and black 1.5 meter cable with plugable M8 eyelets or clamps |
| batteryVoltageNominal | 24 V |
| bluetooth | |
| chargeAlgorithm | Adaptive, 7-stage |
| chargeCurrentLow | 4 A |
| chargeCurrentNormal | 13 A |
| chargeVoltageAbsorption | Normal: 28.8V High: 29.4V Lithium: 28.4V |
| chargeVoltageFloat | Normal: 27.6V High: 27.6V Li-ion: 27.0V |
| chargeVoltageStorage | Normal: 26.4V High: 26.4V Li-ion: 27.0V |
| depth | 240 mm |
| efficiency | 94 % |
| emission | EN 55014-1,EN-IEC 61000-3-2,EN-IEC 61000-6-3 |
| height | 75 mm |
| immunity | EN 55014-2,EN-IEC 61000-3-3,EN-IEC 61000-6-1, EN-IEC 61000-6-2 |
| lithiumCompatible | True |
| maxHumidity | 95 % |
| ouputFullRated | |
| powerSupplyMode | True |
| Programable | True |
| protectionCategory | IP65 |
| protections | Battery reverse polarity,Output short-circuit,Over temperature |
| safety | CSA C22.2,EN-IEC 60335-1,EN-IEC 60335-2-29,UL 1236 |
| standbyPowerConsumption | 0.5 W |
| temperatureCompensation | |
| weight | 1.9 kg |
| width | 140 mm |
Downloads
Datasheet
Enclosure dimension
⬇️ Blue Smart IP65 Charger 12/25 24/13 Charger
⬇️ Blue Smart IP65 Charger 12/25 24/13 Charger (3D)
⬇️ Blue Smart IP65 Charger 12/25 24/13 Charger (stp)
High quality photo
Product Manual
Promo video
System schematic
⬇️ Manual & Drawing Quattro-II 5kVA 230VAC 24VDC 600-800Ah Li Lynx Smart BMS distributors Cerbo generator MPPT Orion Tr Smarts
⬇️ Genless monohull with Victron MultiPlus Lynx Smart BMS NG 600Ah NG Li HP Alternator Wakespeed WS500-Pro regulator
⬇️ Genless catamaran with Victron MultiPlus paralleled Lynx Smart BMS NG 800Ah NG Li HP Alternators Wakespeed WS500-Pro regulators
⬇️ Genless monohull with Victron MultiPlus Lynx Smart BMS NG 600Ah NG Li HP Alternator ARCO Zeus regulator
⬇️ Genless catamaran with Victron MultiPlus paralleled Lynx Smart BMS NG 800Ah NG Li HP Alternators ARCO Zeus regulators
⬇️ Quattro-II 5kVA 230VAC 24VDC 600Ah Li NG Lynx Smart BMS NG distributors Cerbo GX touch generator MPPT Extra Alternator Zeus regulator
⬇️ RV with Quattro 5kVA 120V generator 600Ah 24V Li-NG Lynx Class-T power in Smart BMS-NG Distributors Cerbo GX Touch 70 SBP-220 MPPT 100/50 Arco Zeus Alternator Orion XS 1400 12V Li battery
