Blue Smart IP22 Charger 24 16 3

Blue Smart IP22 Lader 24 16 3

€203,30
€203,30 €214,00
Zu Produktinformationen springen
Blue Smart IP22 Charger 24 16 3
  • Blue Smart IP22 Charger 24 16 3
Blue Smart IP22 Lader 24 16 3

Blue Smart IP22 Lader 24 16 3

€203,30
€203,30 €214,00
Auf Lager
BPC241648102
Terug naar de winkel
De Blue Smart IP22 Charger-lader is de nieuwe professionele acculader met ingebouwde Bluetooth. De Blue Smart IP22 Charger-lader kan worden gebruikt voor apparaten in uw werkplaats en voor motorvoertuigen, zoals (klassieke) auto's, motoren, boten en campers.

Specificaties

Kenmerk Waarde
acConnectionTerminalType Cable of 1.8 meter (6 feet) with US NEMA 5-15 plug
acInputFrequencyRange [45, 65] Hz
aCInputVoltageBucket 120 VAC
automotiveDirective ECE R10-5
batteryConnectionTerminalType
batteryVoltageNominal 24 V
bluetooth True
canBeUsedAsPowerSupply True
chargeAlgorithm Adaptive, 6-stage
chargeCurrentLow 8 A
chargeCurrentNominal 16 A
chargeVoltageAbsorption Normal: 28.8V High: 29.4V Lithium: 28.4V
chargeVoltageFloat Normal: 27.6V High: 27.6V Li-ion: 27.0V
chargeVoltageStorage Normal: 26.4V High: 26.4V Li-ion: 27.0V
colour Blue (RAL 5012)
communicationPorts Bluetooth
depth 65 mm
efficiency 94 %
emission EN 55014-1,EN-IEC 61000-6-3,EN-IEC 61000-3-3
forcedCooling True
height 235 mm
immunity EN 55014-2,EN-IEC 61000-3-3,EN-IEC 61000-6-1, EN-IEC 61000-6-2
lithiumCompatible True
material Aluminium
maxHumidity 98 %
noLoadPowerConsumption 0.5 W
numberOfChargeOutputs 3
operatingTemperatureRange
Programable True
protectionCategory IP22
protections Battery reverse polarity (fuse),Output short-circuit,Over temperature
safety CSA C22.2,EN-IEC 60335-1,EN-IEC 60335-2-29,UL 1236
temperatureCompensation
temperatureSensor Optional (Smart Battery Sense)
weight 1.3 kg
width 108 mm
