MultiPlus C 12 1600 70 16

MultiPlus C 12 1600 70 16

€798,00
€798,00 €840,00
Zu Produktinformationen springen
MultiPlus C 12 1600 70 16
  • MultiPlus C 12 1600 70 16
MultiPlus C 12 1600 70 16

MultiPlus C 12 1600 70 16

€798,00
€798,00 €840,00
Auf Lager
CMP122160000
Terug naar de winkel

De nieuwe stijl MultiPlus is ingesteld om het eerdere MultiPlus Compact-assortiment te vervangen. Het is een krachtige sinusgolf-omvormer, een geavanceerde acculader die beschikt over adaptieve ladingtechnologie en een snelle AC-wisselschakelaar in een enkele compacte behuizing.

Specificaties

Kenmerk Waarde
aCConnectionTerminalType G-ST18i plug
aCInputFrequencyRange [45, 65] Hz
aCInputVoltageRange [187, 265] VAC
aCInputVoltageRange1 [187, 250] VAC
aCOutputFrequency 50 Hz
aCOutputVoltage 230 VAC
antiIslandingStandard See our website
automotiveDirective ECE R10-4
batteryConnectionTerminalType Red and black 1.5 meter cable with M8 eyelets
batteryVoltageNominal 12 V
chargeAlgorithm Adaptive, 4-stage
chargeVoltageAbsorption 14.4 VDC
chargeVoltageFloat 13.8 VDC
chargeVoltageStorage 13.2 VDC
colour Blue (RAL 5012)
communicationPort VE.Bus
computerProgramming True
contPowerVA25 1,600 VA
contPowerW25 1,300 W
contPowerW40 1,200 W
contPowerW65 800 W
dCInputVoltageRange [9.5, 17] VDC
depth 110 mm
dIPSwitchesProgramming True
emissionImmunity EN 55014-1,EN 55014-2,EN-IEC 61000-3-2,EN-IEC 61000-3-3,EN-IEC 61000-6-1, EN-IEC 61000-6-2,EN-IEC 61000-6-3
fanAssistCooling True
frequencySelect 50Hz or 60Hz
height 375 mm
material Aluminium
maxAltitude 2,000 m
maxEfficiency 93 %
maxHumidity 95 %
maximumBatteryChargeCurrent 70 A
operatingTempRange
ovciiiIcw 6kA 30mS
parallelOperation True
peakPowerRating 3,000 W
pollutionDegree 2
powerAssist True
powerControl True
powerFactor 1
programmableRelay AC rating: 230V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC
protectionCategory IP20
protections Output short-circuit,Overload,High battery voltage,Low battery voltage,Over temperature,AC voltage on inverter output,Excessive DC ripple
relayTerminal Screw terminal 3-pole
remoteTerminal On / Off / Charger only
remoteTerminalType Screw terminal two pole
safety EN-IEC 60335-1,EN-IEC 60335-2-29,EN-IEC 62109-1
starterBatteryChargeCurrent 4 A
starterBatteryChargeOutput True
temperatureSensor Included
threePhaseOperation True
transferSwitchCurrentRating 16 A
upsStandard Please consult the certificates on our website
vebusTerminalType Two RJ45 terminals
weight 10 kg
width 214 mm
zeroLoadPower 8 W
zeroLoadPowerAES 5 W
zeroLoadPowerSearch 2 W

Downloads

Brochure

Enclosure dimension

Promo video

Quick installation guide

System schematic

Technical information

Video
