Inverter 12 250 VE Direct UK BS 1363

Omvormer 12 250 VE Direct UK BS 1363

€88,35
€88,35 €93,00
Zu Produktinformationen springen
Inverter 12 250 VE Direct UK BS 1363
  • Inverter 12 250 VE Direct UK BS 1363
Omvormer 12 250 VE Direct UK BS 1363

Omvormer 12 250 VE Direct UK BS 1363

€88,35
€88,35 €93,00
Auf Lager
PIN121251400
Terug naar de winkel

Met omvormers kunt u huishoudelijke apparaten, die 230 V- of 120 V-wisselstroom vereisen, voeden met 'recreatie-' of 'auto'-accu's met een vermogen van 12 V-, 24 V- of 48 V-gelijkstroom.

Specificaties

Kenmerk Waarde
aCOutletSocket UK (BS 1363)
aCOutputVoltage 230 V
automotiveDirective ECE R10-4
batteryChargedDetectionVoltage 14 V
batteryConnectionTerminalType
batteryVoltageNominal 12 V
colour Blue (RAL 5012)
communicationPort VE.Direct
contPowerVA25 250 VA
contPowerW25 200 W
contPowerW40 175 W
dCInputVoltageRange [9.2, 17] V
dCLowRestartAlarm 10.9 V
dCLowShutDown 9.3 V
depth 260 mm
dynamicLowDCShutdown True
ecoModeRetryInterval 2.5 s
ecoModeStopStartPowerSetting Adjustable
eMC EN 55014-1,EN 55014-2,EN-IEC 61000-6-1, EN-IEC 61000-6-2,EN-IEC 61000-6-3
frequency 50 Hz
fullyProgramable True
height 86 mm
material Steel chassis and plastic cover
maxEfficiency 87 %
maxHumidity 95 %
peakPowerRating 400 W
powerDeration 1.25 %
protectionCategory IP21
protections Excessive DC ripple,High battery voltage,Low battery voltage,Output short-circuit,Over temperature,Overload
remoteOnOffTerminal True
remoteTerminal Screw terminal two pole
safety EN-IEC 60335-1,EN-IEC 62109-1
weight 2.4 kg
width 165 mm
zeroLoadPower 4.2 W
zeroLoadPowerEcoMode 0.8 W

Downloads

Datasheet

Enclosure dimension

Product Manual

Promo video

System schematic

Technical information

Video
