Inverter 12 375 VE Direct IEC

Omvormer 12 375 VE Direct IEC

€114,00
€114,00 €120,00
Zu Produktinformationen springen
Inverter 12 375 VE Direct IEC
  • Inverter 12 375 VE Direct IEC
Omvormer 12 375 VE Direct IEC

Omvormer 12 375 VE Direct IEC

€114,00
€114,00 €120,00
Auf Lager
PIN121371100
Terug naar de winkel

Met omvormers kunt u huishoudelijke apparaten, die 230 V- of 120 V-wisselstroom vereisen, voeden met 'recreatie-' of 'auto'-accu's met een vermogen van 12 V-, 24 V- of 48 V-gelijkstroom.

Specificaties

Kenmerk Waarde
aCOutletSocket IEC-320 (male plug included)
aCOutputVoltage 230 VAC
automotiveDirective ECE R10-4
batteryChargedDetectionVoltage 14 VDC
batteryConnectionTerminalType
batteryVoltageNominal 12 VDC
colour Blue (RAL 5012)
communicationPort VE.Direct
contPowerVA25 375 VA
contPowerW25 300 W
contPowerW40 260 W
dCInputVoltageRange [9.2, 17] VDC
dCLowRestartAlarm 10.9 VDC
dCLowShutDown 9.3 VDC
depth 260 mm
ecoModeRetryInterval 2.5 s
ecoModeStopStartPowerSetting Adjustable
emission EN 55014-1,EN-IEC 61000-6-1, EN-IEC 61000-6-2,EN-IEC 61000-6-3
frequency 50 Hz
height 86 mm
material Steel chassis and plastic cover
maxEfficiency 89 %
maxHumidity 95 %
operatingTempRange
peakPowerRating 700 W
powerDeration 1.25 %
protectionCategory IP21
protections Output short-circuit,Overload,High battery voltage,Low battery voltage,Excessive temperature,Excessive DC ripple
remoteOnOffTerminal True
remoteTerminal Screw terminals
safety EN 60335-1,EN/IEC 62109-1
weight 3 kg
width 165 mm
zeroLoadPower 5.6 W
zeroLoadPowerEcoMode 0.9 W

Downloads

Datasheet

Enclosure dimension

Product Manual

Promo video

System schematic

Technical information

Video
