Inverter 12 800 VE Direct UK BS 1363

Omvormer 12 800 VE Direct UK BS 1363

€230,85
€230,85 €243,00
Zu Produktinformationen springen
Inverter 12 800 VE Direct UK BS 1363
  • Inverter 12 800 VE Direct UK BS 1363
Omvormer 12 800 VE Direct UK BS 1363

Omvormer 12 800 VE Direct UK BS 1363

€230,85
€230,85 €243,00
Auf Lager
PIN121801400
Terug naar de winkel

Met omvormers kunt u huishoudelijke apparaten, die 230 V- of 120 V-wisselstroom vereisen, voeden met 'recreatie-' of 'auto'-accu's met een vermogen van 12 V-, 24 V- of 48 V-gelijkstroom.

Specificaties

Kenmerk Waarde
aCOutletSocket UK (BS 1363)
aCOutputVoltage 230 V
automotiveDirective ECE R10-4
batteryChargedDetectionVoltage 14 V
batteryConnectionTerminalType
batteryVoltageNominal 12 V
colour Blue (RAL 5012)
communicationPort VE.Direct
contPowerVA25 800 VA
contPowerW25 650 W
contPowerW40 560 W
dCInputVoltageRange [9.2, 17] V
dCLowRestartAlarm 10.9 V
dCLowShutDown 9.3 V
depth 325 mm
dynamicLowDCShutdown True
ecoModeRetryInterval 2.5 s
ecoModeStopStartPowerSetting Adjustable
eMC EN 55014-1,EN 55014-2,EN-IEC 61000-6-1, EN-IEC 61000-6-2,EN-IEC 61000-6-3
frequency 50 Hz
fullyProgramable True
height 105 mm
material Steel chassis and plastic cover
maxEfficiency 90 %
maxHumidity 95 %
operatingTempRange
peakPowerRating 1,500 W
powerDeration 1.25 %
protectionCategory IP21
protections Excessive DC ripple,High battery voltage,Low battery voltage,Output short-circuit,Over temperature,Overload
remoteOnOffTerminal True
remoteTerminal Screw terminal two pole
safety EN-IEC 60335-1,EN-IEC 62109-1
weight 5.5 kg
width 230 mm
zeroLoadPower 6.5 W
zeroLoadPowerEcoMode 1 W

Downloads

Datasheet

Enclosure dimension

High quality photo

Product Manual

Promo video

System schematic

Technical information

Video
