Inverter 12 375 VE Direct NEMA 5 15R
  • Inverter 12 375 VE Direct NEMA 5 15R
Omvormer 12 375 VE Direct NEMA 5 15R

Omvormer 12 375 VE Direct NEMA 5 15R

€107,35
€107,35 €113,00
Auf Lager
PIN123750500
Terug naar de winkel

Met omvormers kunt u huishoudelijke apparaten, die 230 V- of 120 V-wisselstroom vereisen, voeden met 'recreatie-' of 'auto'-accu's met een vermogen van 12 V-, 24 V- of 48 V-gelijkstroom.

Specificaties

Kenmerk Waarde
aCOutletSocket Nema 5-15R
aCOutputVoltage 120 V
automotiveDirective ECE R10-4
batteryChargedDetectionVoltage 14 V
batteryConnectionTerminalType
batteryVoltageNominal 12 V
colour Blue (RAL 5012)
communicationPort VE.Direct
contPowerVA25 375 VA
contPowerW25 300 W
contPowerW40 260 W
dCInputVoltageRange [9.2, 17] V
dCLowRestartAlarm 10.9 V
dCLowShutDown 9.3 V
depth 260 mm
dynamicLowDCShutdown True
ecoModeRetryInterval 2.5 s
ecoModeStopStartPowerSetting Adjustable
eMC EN 55014-1,EN 55014-2,EN-IEC 61000-6-1, EN-IEC 61000-6-2,EN-IEC 61000-6-3
frequency 60 Hz
fullyProgramable True
height 86 mm
material Steel chassis and plastic cover
maxEfficiency 89 %
maxHumidity 95 %
operatingTempRange
peakPowerRating 700 W
powerDeration 1.25 %
protectionCategory IP21
protections Excessive DC ripple,High battery voltage,Low battery voltage,Output short-circuit,Over temperature,Overcurrent,Overvoltage
remoteOnOffTerminal True
remoteTerminal Screw terminal two pole
safety EN-IEC 60335-1,EN-IEC 62109-1
weight 3 kg
width 165 mm
zeroLoadPower 5.6 W
zeroLoadPowerEcoMode 0.9 W

Downloads

Datasheet

Enclosure dimension

High quality photo

Product Manual

Promo video

System schematic

Technical information

Video
