Inverter 48 375 VE Direct Schuko

Omvormer 48 375 VE Direct Schuko

€126,35
€126,35 €133,00
Zu Produktinformationen springen
Inverter 48 375 VE Direct Schuko
  • Inverter 48 375 VE Direct Schuko
Omvormer 48 375 VE Direct Schuko

Omvormer 48 375 VE Direct Schuko

€126,35
€126,35 €133,00
Auf Lager
PIN481371200
Terug naar de winkel

Met omvormers kunt u huishoudelijke apparaten, die 230 V- of 120 V-wisselstroom vereisen, voeden met 'recreatie-' of 'auto'-accu's met een vermogen van 12 V-, 24 V- of 48 V-gelijkstroom.

Specificaties

Kenmerk Waarde
aCOutletSocket Schuko (CEE 7/4)
aCOutputVoltage 230 V
automotiveDirective ECE R10-4
batteryChargedDetectionVoltage 56 V
batteryConnectionTerminalType
batteryVoltageNominal 48 V
colour Blue (RAL 5012)
communicationPort VE.Direct
contPowerVA25 375 VA
contPowerW25 300 W
contPowerW40 260 W
dCInputVoltageRange [36.8, 62] V
dCLowRestartAlarm 43.6 V
dCLowShutDown 37.2 V
depth 260 mm
dynamicLowDCShutdown True
ecoModeRetryInterval 2.5 s
ecoModeStopStartPowerSetting Adjustable
eMC EN 55014-1,EN 55014-2,EN-IEC 61000-6-1, EN-IEC 61000-6-2,EN-IEC 61000-6-3
frequency 50 Hz
fullyProgramable True
height 86 mm
material Steel chassis and plastic cover
maxEfficiency 90 %
maxHumidity 95 %
operatingTempRange
peakPowerRating 700 W
powerDeration 1.25 %
protectionCategory IP21
protections Excessive DC ripple,High battery voltage,Low battery voltage,Output short-circuit,Over temperature,Overload
remoteOnOffTerminal True
remoteTerminal Screw terminal two pole
safety EN-IEC 60335-1,EN-IEC 62109-1
weight 3 kg
width 165 mm
zeroLoadPower 8.5 W
zeroLoadPowerEcoMode 2.6 W

Downloads

Datasheet

Enclosure dimension

High quality photo

Product Manual

Promo video

System schematic

Technical information

Video
