MultiPlus 12 500 20 16

MultiPlus 12 500 20 16

€313,50
€313,50 €330,00
Zu Produktinformationen springen
MultiPlus 12 500 20 16
  • MultiPlus 12 500 20 16
MultiPlus 12 500 20 16

MultiPlus 12 500 20 16

€313,50
€313,50 €330,00
Auf Lager
PMP121500000
Terug naar de winkel
De MultiPlus nieuwe stijl gaat de eerdere MultiPlus Compact-reeks vervangen. Het is een krachtige zuivere sinusgolfomvormer, een geavanceerde acculader met adaptieve laadtechnologie en een supersnelle AC-wisselschakelaar in een enkele compacte behuizing.

Specificaties

Kenmerk Waarde
aCConnectionTerminalType G-ST18i plug
aCInputFrequencyRange [45, 65] Hz
aCInputVoltageRange [187, 265] VAC
aCOutputFrequency 50 Hz
aCOutputVoltage 230 VAC
antiIslandingStandard Please consult the certificates on our website
automotiveDirective ECE R10-5
batteryConnectionTerminalType
batteryVoltageNominal 12 V
chargeAlgorithm Adaptive, 4-stage
chargeVoltageAbsorption 14.4 VDC
chargeVoltageFloat 13.8 VDC
chargeVoltageStorage 13.2 VDC
colour Blue (RAL 5012)
communicationPort VE.Bus
communicationPortGeneral
computerProgramming True
contPowerVA25 500 VA
contPowerW25 430 W
contPowerW40 400 W
contPowerW65 300 W
dCInputVoltageRange [9.5, 17] VDC
depth 100 mm
dIPSwitchesProgramming True
emissionImmunity EN 55014-1,EN 55014-2,EN-IEC 61000-3-2,EN-IEC 61000-3-3,EN-IEC 61000-6-1, EN-IEC 61000-6-2,EN-IEC 61000-6-3
fanAssistCooling True
height 311 mm
internalDCFuseRating 125 A
material Steel chassis with ABS cover
maxAltitude 2,000 m
maxEfficiency 90 %
maxHumidity 95 %
maximumBatteryChargeCurrent 20 A
operatingTempRange
ovciiiIcw
parallelOperation True
peakPowerRating 900 W
powerAssist
powerControl
programmableRelay AC rating: 230V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC
protectionCategory IP21
protections Output short-circuit,Overload,High battery voltage,Low battery voltage,Over temperature,AC voltage on inverter output,Excessive DC ripple
relayTerminal Screw terminal 3-pole
remoteTerminal On / Off / Charger only
remoteTerminalType Screw terminal two pole
safety EN-IEC 60335-1,EN-IEC 60335-2-29,EN-IEC 62109-1
starterBatteryChargeCurrent 1 A
starterBatteryChargeOutput True
temperatureSensor Included
threePhaseOperation True
transferSwitchCurrentRating 16 A
upsStandard Please consult the certificates on our website
vebusTerminalType One RJ45 terminal, RJ45-spliter ASS030065510 to expand to two ports
weight 4.4 kg
width 182 mm
zeroLoadPower 6 W
zeroLoadPowerSearch 2 W
