MultiPlus 48 1600 20 16

MultiPlus 48 1600 20 16

€489,25
€489,25 €515,00
Zu Produktinformationen springen
MultiPlus 48 1600 20 16
  • MultiPlus 48 1600 20 16
MultiPlus 48 1600 20 16

MultiPlus 48 1600 20 16

€489,25
€489,25 €515,00
Auf Lager
PMP482160000
Terug naar de winkel
De MultiPlus nieuwe stijl gaat de eerdere MultiPlus Compact-reeks vervangen. Het is een krachtige zuivere sinusgolfomvormer, een geavanceerde acculader met adaptieve laadtechnologie en een supersnelle AC-wisselschakelaar in een enkele compacte behuizing.

Specificaties

Kenmerk Waarde
aCConnectionTerminalType G-ST18i plug
aCInputFrequencyRange [45, 65] Hz
aCInputVoltageRange [187, 265] VAC
aCOutputFrequency 50 Hz
aCOutputVoltage 230 VAC
antiIslandingStandard
automotiveDirective ECE R10-4
batteryConnectionTerminalType
batteryVoltageNominal 48 V
chargeAlgorithm Adaptive, 4-stage
chargeVoltageAbsorption 57.6 VDC
chargeVoltageFloat 55.2 VDC
chargeVoltageStorage 52.8 VDC
colour Blue (RAL 5012)
communicationPort VE.Bus
computerProgramming True
contPowerVA25 1,600 VA
contPowerW25 1,300 W
contPowerW40 1,100 W
contPowerW65 800 W
dCInputVoltageRange [38, 66] VDC
depth 120 mm
dIPSwitchesProgramming True
emissionImmunity EN 55014-1,EN 55014-2,EN-IEC 61000-3-2,EN-IEC 61000-3-3,EN-IEC 61000-6-1, EN-IEC 61000-6-2,EN-IEC 61000-6-3
externalAcCurrentSensor
fanAssistCooling True
frequencySelect
height 470 mm
internalDCFuseRating 60 A
material Steel chassis with ABS cover
maxAltitude 2,000 m
maxEfficiency 95 %
maxHumidity 95 %
maximumBatteryChargeCurrent 20 A
operatingTempRange
ovciiiIcw
parallelOperation True
peakPowerRating 2,800 W
powerAssist True
powerControl True
programmableRelay AC rating: 230V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC
protectionCategory IP21
protections Output short-circuit,Overload,High battery voltage,Low battery voltage,Over temperature,AC voltage on inverter output,Excessive DC ripple
relayTerminal Screw terminal 3-pole
remoteTerminal On / Off
remoteTerminalType Screw terminal two pole
safety EN-IEC 60335-1,EN-IEC 60335-2-29,EN-IEC 62109-1
temperatureSensor Included
threePhaseOperation True
transferSwitchCurrentRating 16 A
upsStandard
vebusTerminalType One RJ45 terminal, RJ45-spliter ASS030065510 to expand to two ports
weight 10.2 kg
width 265 mm
zeroLoadPower 10 W
zeroLoadPowerSearch 3 W

Downloads

Brochure

Datasheet

Enclosure dimension

Product Manual

Promo video

System schematic

Technical information

Video
