Quattro II 48 5000 70 50 50

Quattro II 48 5000 70 50 50

€1.190,35
€1.190,35 €1.253,00
Zu Produktinformationen springen
Quattro II 48 5000 70 50 50
  • Quattro II 48 5000 70 50 50
Quattro II 48 5000 70 50 50

Quattro II 48 5000 70 50 50

€1.190,35
€1.190,35 €1.253,00
Auf Lager
QUA482504010
Terug naar de winkel
De Quattro-II is, net zoals de MultiPlus-II, ook een gecombineerde omvormer en lader. Daarnaast kan de Quattro-II twee AC-ingangen accepteren en automatisch de actieve ingang verbinden. De vele functies omvatten een echte sinusgolf omvormer, adaptief laden, hybride PowerAssist technologie en meerdere systeemintegratie functies zoals drie-fasenwerking of gesplitste fase werking.

Specificaties

Kenmerk Waarde
aCConnectionTerminalType
aCInputFrequencyRange [45, 65] Hz
aCInputVoltageRange2 [187, 265] V
aCOutputFrequency 50 Hz
aCOutputVoltage 230 VAC
antiIslandingStandard Please consult the certificates on our website
AuxiliaryOutput True
batteryConnectionTerminalType M8 bolts (two for positive and two for negative connection)
batteryVoltageNominal 48 V
chargeAlgorithm Adaptive, 4-stage
chargeVoltageAbsorption 57.6 VDC
chargeVoltageFloat 55.2 VDC
chargeVoltageStorage 52.8 VDC
colour Blue (RAL 5012)
communicationPort VE.Bus
communicationPortGeneral True
contPowerVA25 5,000 VA
contPowerW25 4,000 W
contPowerW40 3,700 W
dCInputVoltageRange [38, 66] VDC
depth 148 mm
emissionImmunity EN 55014-1,EN 55014-2,EN-IEC 61000-3-2,EN-IEC 61000-3-3,EN-IEC 61000-6-1, EN-IEC 61000-6-2,EN-IEC 61000-6-3
fanAssistCooling True
frequencySelect 50Hz or 60Hz
height 565 mm
integratedTransferSwitch True
material Steel
maxAltitude 2,000 m
maxAppFeedinPower 5,000 VA
maxEfficiency 96 %
maxFeedTroughCurrent 2x 50A
maxHumidity 95 %
maximumBatteryChargeCurrent 70 A
numberAcInputs 2
operatingTempRange
parallelOperation True
peakPowerRating 9,000 W
powerAssist True
powerControl True
programmableRelay AC rating: 230V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC
protectionCategory IP21
protections Output short-circuit,Overload,High battery voltage,Low battery voltage,Over temperature,AC voltage on inverter output,Excessive DC ripple
relayTerminal Screw terminal 3-pole
remoteTerminal On / Off
remoteTerminalType Screw terminal two pole
safety EN-IEC 60335-1,EN-IEC 60335-2-29,EN-IEC 62109-1
temperatureSensor Included
threePhaseOperation True
upsStandard Please consult the certificates on our website
vebusTerminalType Two RJ45 terminals
weight 29 kg
width 320 mm
zeroLoadPower 18 W
zeroLoadPowerAES 12 W
zeroLoadPowerSearch 2 W

Downloads

Datasheet

Enclosure dimension

High quality photo

Promo video

System schematic

Video
