Name: BlueSolar PWM LCD USB 12 24V 10A
Brand: Victron Energy
SKU: SCC010010050
Price: 27.55 EUR
Availability: InStock

BlueSolar PWM LCD USB 12 24V 10A

€27,55

€27,55 €29,00

€27,55

€27,55 €29,00

Auf Lager

SCC010010050

BlueSolar PWM-LCD&USB

LCD scherm
Twee 5 Volt USB-uitgangen
Lichtregelingsfunctie, volledig programmeerbaar
Drietraps acculaden (bulk, absorptie, druppel), volledig programmeerbaar
Belastingsuitgang met lage spanning en handmatige ontkoppeling (programmeerbaar)
Belastingsuitgang beschermd tegen overbelasting en kortsluiting
Beschermd tegen aansluiting met omgekeerde polariteit van de zonnepanelen en / of de accu

BlueSolar PWM DUO-LCD&USB
Alle van bovenstaande functies, plus:

Kenmerk	Waarde
batteryConnectionTerminalType
batteryVoltage	12V / 24V (automatic detection)
chargeVoltageAbsorption	14.4V / 28.8V
chargeVoltageFloat	13.7V / 27.4V
colour	Blue (RAL 5012)
depth	36 mm
emission	EN-IEC 61000-6-1,EN-IEC 61000-6-3,ISO 7637-2
grounding	Common positive
height	96 mm
loadConnectionTerminalType
loadOutput	Manual control + low voltage disconnect +timer
lowVoltageLoadDisconnect	11.2V / 22.4V
lowVoltageLoadReconnect	12.6V / 25.2V
material
maxHumidity	95 %
maxSolarVoltage
numberOfUsbPorts	2
operatingTempRange
otherBatteryConnectionTerminalType
OverloadProtection130	Shutdown after 60 seconds
OverloadProtection160	Shutdown after 5 seconds
OverloadProtectionSC	Immediate shutdown
protectionCategory	IP20
protections	Battery reverse polarity (fuse),Output short-circuit,Excessive temperature
pvArray12v	Solar panel with 36 cells
pvArray24v	Solar panel with 72 cells,Two solar panles with 36 cells in series
pVConnectionTerminalType
ratedChargeCurrent	10 A
remoteOnOffTerminalConnection
remotePanel	No
safety	EN-IEC 60335-1,EN-IEC 62109-1
secondBatteryOutput
selfConsumption	10 mA
temperatureCompensation	No
temperatureSensor	No
uSBCurrent	2 A
uSBVoltage	5 V
weight	0.15 kg
width	169 mm
