Name: BlueSolar PWM LCD USB 48V 20A
Brand: Victron Energy
SKU: SCC040020050
Price: 37.05 EUR
Availability: InStock

BlueSolar PWM LCD USB 48V 20A

€37,05

€37,05 €39,00

€37,05

€37,05 €39,00

Auf Lager

SCC040020050

BlueSolar PWM-LCD&USB

LCD scherm
Twee 5 Volt USB-uitgangen
Lichtregelingsfunctie, volledig programmeerbaar
Drietraps acculaden (bulk, absorptie, druppel), volledig programmeerbaar
Belastingsuitgang met lage spanning en handmatige ontkoppeling (programmeerbaar)
Belastingsuitgang beschermd tegen overbelasting en kortsluiting
Beschermd tegen aansluiting met omgekeerde polariteit van de zonnepanelen en / of de accu

BlueSolar PWM DUO-LCD&USB
Alle van bovenstaande functies, plus:

Kenmerk	Waarde
automaticLoadDisconnect	True
batteryConnectionTerminalType
batteryVoltage	48V
chargeVoltageAbsorption	57.6V
chargeVoltageFloat	54.8V
colour	Blue (RAL 5012)
depth	47 mm
emission	EN-IEC 61000-6-1,EN-IEC 61000-6-3,ISO 7637-2
grounding	Common positive
height	101 mm
loadConnectionTerminalType
loadOutput
lowVoltageLoadDisconnect	44.8V
lowVoltageLoadReconnect	50.4V
material
maxHumidity	95 %
maxSolarVoltage	100V
numberOfUsbPorts	2
operatingTempRange
otherBatteryConnectionTerminalType
OverloadProtection130	Shutdown after 60 seconds
OverloadProtection160	Shutdown after 5 seconds
OverloadProtectionSC	Immediate shutdown
protectionCategory	IP20
protections	Battery reverse polarity (fuse),Output short-circuit,Excessive temperature
pvArray48v	Two solar panles with 72 cells in series,Four solar panles with 36 cells in series
pVConnectionTerminalType
ratedChargeCurrent	20 A
remoteOnOffTerminalConnection
remotePanel	No
safety	EN-IEC 60335-1,EN-IEC 62109-1
secondBatteryOutput
selfConsumption	10 mA
temperatureCompensation	No
temperatureSensor	No
uSBCurrent	2 A
uSBVoltage	5 V
weight	0.3 kg
width	184 mm
