er Blue Smart IP22 Charger 24 16 1
€171,00
Sale price
€171,00
Regular price
€180,00
Skip to product information
In stock
Back to the store
The Blue Smart IP22 Charger is the new professional battery charger with built-in Bluetooth. It can be used for devices in your workshop and for motor vehicles, such as (classic) cars, motorcycles, boats, and campers.
er Blue Smart IP22 Charger 24 16 1
€171,00
Sale price
€171,00
Regular price
€180,00
BPC241647002
Specifications
| Feature | Value |
|---|---|
| acConnectionTerminalType | |
| acInputFrequencyRange | [45, 65] Hz |
| aCInputVoltageRange | [180, 265] VAC |
| automotiveDirective | ECE R10-5 |
| batteryConnectionTerminalType | |
| batteryVoltageNominal | 24 V |
| Bluetooth | True |
| canBeUsedAsPowerSupply | True |
| chargeAlgorithm | Adaptive, 6-stage |
| chargeCurrentLow | 8 A |
| chargeCurrentNormal | 16 A |
| chargeVoltageAbsorption | Normal: 28.8V High: 29.4V Lithium: 28.4V |
| chargeVoltageFloat | Normal: 27.6V High: 27.6V Li-ion: 27.0V |
| chargeVoltageStorage | Normal: 26.4V High: 26.4V Li-ion: 27.0V |
| color | Blue (RAL 5012) |
| communicationPorts | Bluetooth |
| depth | 65 mm |
| efficiency | 94% |
| emission | EN 55014-1, EN-IEC 61000-3-2, EN-IEC 61000-6-3 |
| forced cooling | True |
| height | 235 mm |
| immunity | EN 55014-2, EN-IEC 61000-3-3, EN-IEC 61000-6-1, EN-IEC 61000-6-2 |
| lithiumCompatible | True |
| material | Aluminum |
| maxHumidity | 98% |
| noLoadPowerConsumption | 0.5 W |
| numberOfChargeOutputs | 1 |
| operatingTemperatureRange | |
| Programmable | True |
| protection Category | IP22 |
| protections | Battery reverse polarity (fuse),Output short circuit,Over temperature |
| safety | EN-IEC 60335-1, EN-IEC 60335-2-29 |
| temperatureCompensation | |
| temperatureSensor | Optional (Smart Battery Sense) |
| weight | 1.3 kg |
| width | 108 mm |
Downloads
Datasheet
Enclosure dimension
⬇️ Blue Smart IP22 Charger 230V
⬇️ Blue Smart IP22 Charger 230V (3D)
⬇️ Blue Smart IP22 Charger 230V (stp)
