Orion Tr 24 12 15 180W
€38,00
Sale price
€38,00
Regular price
€40,00
Skip to product information
In stock
Back to the store
Orion Tr 24 12 15 180W
€38,00
Sale price
€38,00
Regular price
€40,00
ORI241215200
Highly efficient: Utilizing synchronous rectification, full load efficiency is higher than 95%.
IP43 protection: If the screw terminals are installed facing downwards.
Screw Clamps: No special tools required for installation.
Specifications
| Feature | Value |
|---|---|
| automotiveDirective | ECE R10-4 |
| color | Blue (RAL 5012) |
| continuousOutputCurrent | 15 A |
| dcConnectionTerminalType | |
| depth | 45 mm |
| emission | EN 55014-1, EN-IEC 61000-6-3 |
| height | 73 mm |
| immunity | EN 55014-2, EN-IEC 61000-6-1, EN-IEC 61000-6-2 |
| inputVoltageRange | [18, 35] V |
| material | |
| maxEfficiency | 97 |
| maximumOutputCurrent | 20 A |
| offLoadCurrent | 35 |
| operatingTempRange | |
| outputDeratingAbove40 | 3% |
| output Voltage | 12.5 V |
| relayTerminalConnection1 | |
| remoteOnOffTerminalConnection | |
| safety | EN 60950 |
| temperatureSensor | |
| weight | 0.25 kg |
| width | 94 mm |
Downloads
Datasheet
Enclosure dimension
High quality photo
⬇️ Orion-Tr 24/12-5 (60W) DC-DC converter (top)
⬇️ Orion-Tr 24/12-5 (60W) DC-DC converter (front2)
⬇️ Orion-Tr 24/12-5 (60W) DC-DC converter (right)
⬇️ Orion-Tr 24/12-5 (60W) DC-DC converter (left)
⬇️ Orion-Tr 24/12-10 (120W) DC-DC converter (top)
⬇️ Orion-Tr 24/12-10 (120W) DC-DC converter (front)
⬇️ Orion-Tr 24/12-10 (120W) DC-DC converter (right)
⬇️ Orion-Tr 24/12-10 (120W) DC-DC converter (left)
⬇️ Orion-Tr 24/12-15 (180W) DC-DC converter (top)
⬇️ Orion-Tr 24/12-15 (180W) DC-DC converter (front)
⬇️ Orion-Tr 24/12-15 (180W) DC-DC converter (right)
⬇️ Orion-Tr 24/12-15 (180W) DC-DC converter (left)
⬇️ Orion-Tr 24/12-20 (240W) (top)
⬇️ Orion-Tr 24/12-20 (240W) (front)
⬇️ Orion-Tr 24/12-20 (240W) (top angle)
