Orion 24 12 40

Orion 24 12 40

€85,50
€85,50 €90,00
Skip to product information
Orion 24 12 40
  • Orion 24 12 40
Orion 24 12 40

Orion 24 12 40

€85,50
€85,50 €90,00
In stock
ORI241240021
Back to the store

Remote On/Off Button
The remote on/off switch eliminates the need for a high-current switch in the input wiring. The remote on/off switch can be operated with a low-current switch or, for example, the motor's on/off switch (see manual).

All models with an adjustable output voltage can also be used as a battery charger, for example to charge a 12 volt starter or accessory battery in a 24 V system.

All models with adjustable output voltage can be connected in parallel to increase output power. Up to five units can be connected in parallel.

Specifications

Feature Value
automotiveDirective ECE R10-4
color Blue (RAL 5012)
dcConnectionTerminalType Faston tab 6.3 mm
depth 185 mm
emission EN 55014-1, EN-IEC 61000-6-3
fanAssistedCooling True
height 65 mm
immunity EN 55014-2, EN-IEC 61000-6-1, EN-IEC 61000-6-2
inputVoltageRange [18, 35] V
material Aluminum
maxEfficiency 95
maximumOutputCurrent 555 A
offLoadCurrent 20
operatingTempRange
outputDeratingAbove40 40%
output Voltage 13.2 V
relayTerminalConnection1
remoteOnOffTerminal True
remoteOnOffTerminalConnection Screw terminal two pole
safety EN 60950
temperatureSensor
underVoltageRestart 18 V
underVoltageShutdown 14 V
weight 0.58 kg
width 88 mm

Downloads

Brochure

Datasheet

Enclosure dimension

High quality photo

⬇️ Orion 24/12-25A DC-DC converter IP20 (top) ⬇️ Orion 24/12-25A DC-DC converter IP20 (front) ⬇️ Orion 24/12-25A DC-DC converter IP20 (right) ⬇️ Orion 24/12-25A DC-DC converter IP20 (left) ⬇️ Orion 24/12-40A DC-DC converter (Uout=13.2V) (top) ⬇️ Orion 24/12-40A DC-DC converter (Uout=13.2V) (front) ⬇️ Orion 24/12-40A DC-DC converter (Uout=13.2V) (right) ⬇️ Orion 24/12-40A DC-DC converter (Uout=13.2V) (left) ⬇️ Orion 24/12-70A DC-DC converter IP20 (top) ⬇️ Orion 24/12-70A DC-DC converter IP20 (front) ⬇️ Orion 24/12-70A DC-DC converter IP20 (right) ⬇️ Orion 24/12-70A DC-DC converter IP20 (left) ⬇️ Orion 24/12-70 with binding posts (left) ⬇️ Orion 12/24-8 DC-DC converter IP20 (top) ⬇️ Orion 12/24-8 DC-DC converter IP20 (front) ⬇️ Orion 12/24-8 DC-DC converter IP20 (right) ⬇️ Orion 12/24-8 DC-DC converter IP20 (left) ⬇️ Orion 12/24-10 DC-DC converter IP20 (top) ⬇️ Orion 12/24-10 DC-DC converter IP20 (front) ⬇️ Orion 12/24-10 DC-DC converter IP20 (right) ⬇️ Orion 12/24-10 DC-DC converter IP20 (left) ⬇️ Orion 12/24-20 DC-DC converter IP20 (top) ⬇️ Orion 12/24-20 DC-DC converter IP20 (front) ⬇️ Orion 12/24-20 DC-DC converter IP20 (right) ⬇️ Orion 12/24-20 DC-DC converter IP20 (left) ⬇️ Orion 24/12-25A DC-DC converter IP20 (front) ⬇️ Orion 24/12-25A DC-DC converter IP20 (front2) ⬇️ Orion 24/12-25A DC-DC converter IP20 (left) ⬇️ Orion 24/12-25A DC-DC converter IP20 (right) ⬇️ Orion 24/12-25A DC-DC converter IP20 (top) ⬇️ Orion 24/12-40A DC-DC converter (Uout=13.2V) (front) ⬇️ Orion 24/12-40A DC-DC converter (Uout=13.2V) (front2) ⬇️ Orion 24/12-40A DC-DC converter (Uout=13.2V) (left) ⬇️ Orion 24/12-40A DC-DC converter (Uout=13.2V) (right) ⬇️ Orion 24/12-40A DC-DC converter (Uout=13.2V) (top) ⬇️ Orion 24/12-70A DC-DC converter IP20 (top) ⬇️ Orion 24/12-70A DC-DC converter IP20 (front) ⬇️ Orion 24/12-70A DC-DC converter IP20 (front2) ⬇️ Orion 24/12-70A DC-DC converter IP20 (right) ⬇️ Orion 24/12-70A DC-DC converter IP20 (left) ⬇️ Orion 12/24-10 DC-DC converter IP20 (front) ⬇️ Orion 12/24-10 DC-DC converter IP20 (front2) ⬇️ Orion 12/24-10 DC-DC converter IP20 (left) ⬇️ Orion 12/24-10 DC-DC converter IP20 (right) ⬇️ Orion 12/24-10 DC-DC converter IP20 (top)

Press release

Product Manual
