Inverter 24 5000 Smart
  • Inverter 24 5000 Smart
Inverter 24 5000 Smart

Inverter 24 5000 Smart

€1.530,45
€1.530,45 €1.611,00
In stock
PIN242501000
Back to the store
The Phoenix Inverter Smart is an efficient and reliable inverter. Built on our proven and field-tested platform, it now features a sleeker design and a full metal casing. Models are available in 1600 VA, 2000 VA, 3000 VA, and 5000 VA for 12, 24, or 48V systems.

It's powerful enough to power most plug-in devices in your car, boat, caravan, or home. A toroidal transformer provides high peak current capacity, stable voltage and frequency, and high-quality sine wave.

Installation is easier than ever with clamps that are more accessible to the installer and allow for a more professional finish.

Bluetooth is built-in, making configuring your high-power inverter easier than ever. Configure alarms, alarm relays, voltage cutoff, eco mode, and much more. All from VictronConnect.

Specifications

Feature Value
acConnection Screw terminals
aCOutputVoltage 230 V
automotiveDirective ECE R10-5
batteryConnection
batteryVoltageNominal 24 V
Bluetooth True
color Blue (RAL 5012) and Black (RAL 9017)
communicationPort Bluetooth,VE.Direct
contPowerVA25 5,000 VA
contPowerW25 4,000 W
contPowerW40 3,700 W
contPowerW65 2,800 W
dCInputVoltageRange [18.6, 34] V
depth 160 mm
dynamicLowDCShutdown True
ecoModeStopStartPowerSetting Adjustable
emissionImmunity EN 55014-1, EN 55014-2, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3
frequency1 50Hz or 60Hz
fully programmable True
height 595 mm
material Steel
maxEfficiency 95%
maxHumidity 95%
operatingTempRange
parallel3phase True
peakPowerRating 10,000 W
programmableRelay AC rating: 230V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC
protection Category IP21
protections Output short-circuit,Overload,High battery voltage,Low battery voltage,Over temperature,AC voltage on inverter output,Excessive DC ripple
relay terminal Screw terminal 3-pole
remoteOnOffTerminal True
remoteTerminal Screw terminal two pole
safety EN-IEC 60335-1
weight 29 kg
width 195 mm
zeroLoadPower 18 W
zeroLoadPowerEcoMode 2.2 W
