Inverter 48 1200 VE Direct NEMA GFCI UL 458

Inverter 48 1200 VE Direct NEMA GFCI UL 458

€333,45
€333,45 €351,00
Skip to product information
Inverter 48 1200 VE Direct NEMA GFCI UL 458
  • Inverter 48 1200 VE Direct NEMA GFCI UL 458
Inverter 48 1200 VE Direct NEMA GFCI UL 458

Inverter 48 1200 VE Direct NEMA GFCI UL 458

€333,45
€333,45 €351,00
In stock
PIN482122510
Back to the store

Inverters allow you to power household appliances requiring 230V or 120V AC using 'leisure' or 'car' batteries rated at 12V, 24V or 48V DC.

Specifications

Feature Value
aCOutletSocket Nema 5-15R
aCOutputVoltage 120 V
automotiveDirective ECE R10-4
batteryChargedDetectionVoltage 56 V
batteryConnectionTerminalType
batteryVoltageNominal 48 V
color Blue (RAL 5012)
communicationPort VE.Direct
contPowerVA25 1,200 VA
contPowerW25 1,000 W
contPowerW40 850 W
dCInputVoltageRange [36.8, 62] V
dCLowRestartAlarm 43.6 V
dCLowShutDown 37.2 V
depth 327 mm
dynamicLowDCShutdown True
ecoModeRetryInterval 2.5 s
ecoModeStopStartPowerSetting Adjustable
eMC EN 55014-1, EN 55014-2, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3
frequency 60 Hz
fully programmable True
height 117 mm
material Steel chassis and plastic cover
maxEfficiency 92%
maxHumidity 95%
operatingTempRange
peakPowerRating 2,200 W
powerDeration 1.25%
protection Category IP21
protections Excessive DC ripple,High battery voltage,Low battery voltage,Output short circuit,Over temperature,Overload
remoteOnOffTerminal True
remoteTerminal Screw terminal two pole
safety EN-IEC 60335-1, EN-IEC 62109-1
weight 7.4 kg
width 232 mm
zeroLoadPower 10 W
zeroLoadPowerEcoMode 3 W
