MultiPlus II 24 5000 120 95 120V
€1.643,50
Sale price
€1.643,50
Regular price
€1.730,00
PMP242505110
The MultiPlus-II is a multifunctional inverter/charger with two AC outputs. Suitable for professional marine, marine, automotive, and land-based self-sufficient systems, it also provides the isolation and redundancy required for ESS installations. With PowerControl, the MultiPlus-II prevents overloading of the utility grid or generator, while PowerAssist boosts AC output during peak demand. In the event of a power outage, the inverter switches over within milliseconds, ensuring computers and sensitive electronics continue to operate without interruption. The charger combines speed and efficiency through a smart adaptive algorithm that extends battery life. The MultiPlus-II is expandable and supports parallel and three-phase configurations should a system need to be expanded.
Note: For a short time this product was called MultiGrid-II.
Specifications
| Feature | Value |
|---|---|
| aCConnectionTerminalType | |
| aCInputFrequencyRange | [45, 65] Hz |
| aCInputVoltageRange | [90, 140] VAC |
| aCOutputFrequency | 60 Hz |
| aCOutputVoltage | 120 VAC |
| antiIslandingStandard | |
| AuxiliaryOutput | True |
| batteryConnectionTerminalType | M8 bolts |
| batteryVoltageNominal | 24 V |
| chargeAlgorithm | Adaptive, 4-stage |
| chargeVoltageAbsorption | 28.8 VDC |
| chargeVoltageFloat | 27.6 VDC |
| chargeVoltageStorage | 26.4 VDC |
| color | Blue (RAL 5012) |
| communicationPort | VE.Bus |
| communicationPortGeneral | True |
| computer programming | True |
| contPowerVA25 | 5,000 VA |
| contPowerW25 | 4,000 W |
| contPowerW40 | 3,700 W |
| contPowerW65 | 3,000 W |
| dCInputVoltageRange | [19, 33] VDC |
| depth | 150 mm |
| emissionImmunity | EN 55014-1,EN 55014-2,EN-IEC 61000-3-2,EN-IEC 61000-3-3,EN-IEC 61000-6-1, EN-IEC 61000-6-2,EN-IEC 61000-6-3 |
| externalAcCurrentSensor | 100A (optional) |
| fanAssistCooling | True |
| frequencySelect | |
| height | 627 mm |
| material | Steel |
| maxAcInputCurrent | 95 A |
| maxEfficiency | 95% |
| maxHumidity | 95% |
| maximumBatteryChargeCurrent | 95 A |
| operatingTempRange | |
| ovciiiIcw | |
| parallelOperation | True |
| peakPowerRating | 9,000 W |
| powerAssist | True |
| powerControl | True |
| programmableRelay | AC rating: 120V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC |
| protection Category | IP22 |
| protections | Output short-circuit,Overload,High battery voltage,Low battery voltage,Over temperature,AC voltage on inverter output,Excessive DC ripple |
| relay terminal | Screw terminal 3-pole |
| remoteTerminal | On / Off |
| remoteTerminalType | Screw terminal two pole |
| safety | CSA C22.2 107.1-16,EN-IEC 60335-1,EN-IEC 60335-2-29 |
| temperatureSensor | Included |
| threePhaseOperation | True |
| transferSwitchCurrentRating | 95 A |
| upsStandard | |
| vebusTerminalType | Two RJ45 terminals |
| weight | 29 kg |
| width | 250 mm |
| zeroLoadPower | 24 W |
| zeroLoadPowerAES | 10 W |
| zeroLoadPowerSearch | 3 W |
